Adco AFCX3-30-2-SS, Complete Line
AMERICA North (USA-Canada-Mexico)
Tri Seal servo driven tray line consisting of Adco,
Model AFCXS-30-2-SS automatic,
dual head tray former and Adco Model 16B-60-SS,
automatic hot melt glue tri-seal carton sealer rated
from 5 to 30 cycles per minute with number of trays per minute
depending on materials and application
Tray size range: 3" to 17" in Length; 4" to 8" in
Width each head: 1" to 4.5" in Height.
Capable of handling flat blank sizes up to 26" in Length
and 11-1/2" in Width each head.
Tray former has dual 24" long blank tray magazines,
dual vacuum (3) suction cup recipicating pick-in-place,
mechanical tray forming heads, no tray / no form photo eyes
with Nordson hot melt glue unit and vacuum system.
64" long, servo driven, single chain lugged feed conveyor
with 1½" high lugs set on 16" centers feeding
to 12" wide x 128" long intralox table top product operator
hand load conveyor into continuous motion, lugged,
tri seal carton closer with 132" long lugged chain feed conveyor
set on 24" centers has 2" wide x 2-1/2" high lugs
with 90-degree tray rotation section,
to 74" long dual chain transport conveyor set on 24" centers
with 60" long dual top flap and side flap closing and sealing conveyor
with 22" long side compression section. Nordson hot melt glue
and vacuum systems. Both have control panels
with A/B controllers and touch pad controls.
Both mounted on heavy duty base frames with leveling legs
and cage style interlock safety guarding.
OAD: 132" L x 77" W x 94" H Tray Former
96" L x 89" W x 87" H Tri-Sealer
128" L x 20" W x 36" H Conveyor
356" L x 89" W x 94" H Total Together
