Sumitomo SE450HD-1700 495 T

Ref : 2517644-6-W

Condition : Used

Manufacturer : Sumitomo

Model : SE450HD-1700

Capacity : 495 T

Year(s) : 2007

Quantity : 1

Location : Seller or machines location:
AMERICA North (USA-Canada-Mexico)

Last check : 22 Apr. 2024

TONNAGE: 495 US TON
SHOT SIZE: 33.4 OZ (71 MM)
DISTANCE BETWEEN TIE BAR: 34.2" X 32.2"
PLATEN SIZE: 50.7" X 47.24"
MAXIMUM OPEN DAYLIGHT: 62.9"
MOLD SPACE (MIN/MAX): 21.6"/ 35.4" ( EXTENDED MOLD SPACE OPTION)
MAXIMUM MOLD OPENING STROKE: 31.50"
EJECTOR STROKE: 6.89"
DIMENSIONS: 332" X 83" X 89"
WEIGHT: 53,000 LBS

EQUIPPED WITH:
SUMITOMO NVIII CONTROL
AIR BLOW
(2) VALVE GATES
WIRED FOR CORE PULL
