Biesse ROXYL 5.5

Ref : 2302047-15-MT
Condition : Used
Manufacturer : Biesse
Model : ROXYL 5.5
Year(s) : -
Quantity : 1
Location : Seller or machines location:
EUROPE (Western and Northern)

Numerical Control with Sintra Software

Panel height 65 mm

Long side panel length mm 140 - 3200

Short side panel length mm 85 - 3200

Solid wood 0.4 - 22 mm

Pvc / Abs mm 0,4 - 3

Continuously adjustable feed speed from 10 to 25 mt / min

Working height electronically adjustable by NC

Motorized rubber belt with higher pressure

Input panel support guide electronically adjustable by CN

Side roller conveyor with idle wheels for panel support

"ADZ 700" anti-adhesive group

Rectifier unit with 2 motors electronically adjustable by CN "FI 502"

Single reel holder plate

Electronic edge magazine with 2 positions

Gluing unit for EVA "VC 710" hot melt glue with pre-melting "QM 705"

Infra Led Lamp System "AdIRL 700"

"Air Force Step 2" gluing system that guarantees a perfect finish with greater durability and high resistance to water and heat

Edge pressure group on straight profiles with pressure rollers electronically adjustable by NC

End trimming unit with 2 motors with "IN 801" inclination adjustment

Superimposed trimming unit with 2 "RF100" motors with nesting kit

Rounding unit with 2 multifunction motors (gleaner + rounder) with automatic adjustment by numerical control "AR 30"

Edge scraper group "RB 400" with two positions adjustable by NC

"RC 701" electronic scraper unit adjustable by NC

"LPZ 700" non-stick group

Oscillating brush group "SZ 30"

Hot air unit "PH 700"
